Genie SX-180

Access Lift > Featured Inventory > Genie SX-180

Genie SX-180

Call for price Buy Now

Product Information

Serial #:
Product Drive:4wd
Fuel Type:Diesel
Platform Height:180'
Working Height:186'
Tires:Foam Filled

The Genie SX-180 is a telescopic boom lift that sports the largest reach among models that Genie has to offer. It has an incredible reach of 186 ft vertically and 80 ft horizontally. Consequently, this machine can reach across great distances to places other lifts never could. It also sports a great platform capacity of 750 lb, so there will rarely be an issue with whatever its transporting.

Spec Sheet



The Genie SX-180 is well-equipped for extreme tasks that would trouble any smaller lifts. It offers impressive reach, beyond that of others on the market, while also being remarkably stable thanks to the Genie X-Chassis. Consequently, it is perfectly-suited for work at great far extensions, such as high-elevation window cleaning or power line repairs.

Check Out Our Genie SX-180 Boom Lifts!


Genie SX-180 Specifications at a Glance

The Genie SX-180 offers:

  • 186 ft maximum working height
  • 80 ft horizontal outreach
  • 750 lb. unrestricted platform capacity


Power Source
Power Type Diesel
Capacity – Fuel Tank 50 gal / 189.3 L
Capacity – Hydraulic Tank 110 gal / 416 L


Drive Speed – Stowed 2.3 mph / 3.7 km/h
Drive Speed – Raised 0.4 mph / 0.65 km/h
Gradeability – Stowed 35 %
Platform Capacity – Unrestricted 750 lb / 340 kg
Platform Capacity – Restricted 1000 lb / 454 kg
Maximum Turning Radius – Outside 28 ft 1 in / 8.56 m
Maximum Turning Radius – Inside 20 ft 7 in / 6.28 m


Dimensional Data
Ground Clearance 15 in / 0.38 m
Machine Height 10 ft / 3.05 m
Machine Length 53 ft 1 in / 16.18 m
Machine Width 8 ft 2 in / 2.49 m
Platform Dimension A 3 ft / 0.91 m
Platform Dimension B 8 ft / 2.44 m
Tailswing 3 ft 9 in / 1.14 m
Tire Size 445D50/710


Reach Specifications
Vertical Jib Rotation 135 Degrees
Horizontal Outreach 80 ft / 24.38 m
Platform Height 180 ft / 54.86 m


Tire Contact Pressure 130 psi / 896 kPa
Machine Weight 55,000 lb / 24,948 kg


Contact Access Lift Equipment for More Information

The Genie SX-180 boom lift from is one of many used machines we have in stock. We test and recondition our equipment to perfection before sending it from our Chambersburg, PA or San Diego, CA locations. Our sole focus is helping you find the top-quality machines you require at a competitive price.

Give us a call today to speak with a sales representative, or contact us online to request additional information. We’ll be happy to provide more detailed specifications on any product in our extensive inventory.
